Akiles  |  SKU: ALPHACOIL-E

Akiles AlphaCoil-E Electric Punch & Electric Coil Binding Machine

$769.35
450 (Sheets) Max. Binding Capacity, 20 (Sheets) Punch Capacity, 11" Punch Length With 4:1 Punching Pitch

Click here to find more Binding Supplies & Accessories for Akiles

Brochure View PDF File

User Manual: View PDF File

Product Specifications
Product Name Akiles AlphaCoil-E Electric Punch & Electric Coil Binding Equipment
Manufacturer Akiles
SKU ALPHACOIL-E
Punch Length (inches) 11
Punch Pitch 4:1
Paper Punch Volume (lbs.) 20
Category AlphaCoil
Binding Operation Electric
Binding Type Coil Binding
Punch Operation Electric
Binding Capacity (Diameter") Electric (1) , Manual (2)
Binding Capacity (Sheets) 250 - 450
Number of pitches 1
Paper Size A4 Size
Punch Hole Size (mm) 4
Depth Margin Adjustable
Warranty 1 Year
Included Accessories Coil Crimper & Crimper Holder
Country of Origin Taiwan
User Type Large Office
Closing Mechanism Vertical
Reverse Switch No
Waste Drawer Yes
Side Margin Adjustable
Disengageable Pins 46
Punch Hole Shape Round
Number of Holes 43
Punching Capacity (Sheets) 20
Product Description:

  • Standard 4mm round holes with a pitch of 4:1 for easy binding
  • Fully disengageable pins in the die set for punching all paper sizes neatly
  • All electric operation for quick punching and binding
  • Electric Coil Inserter and coil crimpers part of the package

The Akiles Alphacoil -E electric coil binding equipment is without doubt the best companion to have in busy offices with lots of paperwork. It comes integrated with market-best features and an easy to use design that guarantees users convenient coil binding of their documents.


The Akiles AlphaCoil-E can punch up to 20 sheets of 20 lbs paper in one punching cycle; its die perforates standard 4mm round holes in the paper and is built to a pitch of 4:1. These are universally accepted paperwork standards that not only are best suited to official documents, but also give a professional look to the way people work.


Akiles AlphaCoil-E is very simple to operate due to its all-electric operation mode. It has an electrically controlled punching unit that can be easily operated with the foot pedal this product comes with. Furthermore, it is designed to suit the vastly varying needs of high-end customers. The die set’s pins are fully disengageable, giving users the flexibility to change the punch pattern to suit any paper size. All they need to do is to centre their paper using the handy side margin and depth guides, and disengage the pins that fall out of proportion to the punch pattern.


Akiles electric coil binding machines are well-known for their range of services to users. AlphaCoil-E has been manufactured with the same traits in mind. It is equipped with an electric coil insertion unit that expedites the coil insertion process and saves users time and money. To top this feature off, Akiles also includes a coil crimper and crimper holder in the package so operators can cut off protruding coil ends and produce a perfectly coil-bound document right away.

Frequently Asked Questions

Q) Can we use steel spiral coils for binding?

The Akiles AlphaCoil-E electric punch & electric coil binding equipment is only capable of accommodating standard plastic coils.

Q) What are the dimensions of this machine?

The overall dimensions of this machine are 18”W x 9” D x 11”H.

Q) Is this machine suitable for small offices?

This machine is built to cater large office needs but you can have a look at the ‘Akiles AlphaBind-CM Manual Comb Binding Equipment’ which is designed for small offices.

Video of Akiles AlphaCoil-E Electric Punch & Electric Coil Binding Machine
