MBM Triumph 5560 Programmable Cutter Package
MBM Triumph 5560 Programmable Cutter Package is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
MBM Triumph 5560 Programmable Cutter Package
Spec Sheet: View PDF File
User Manual: View PDF File
Product Specifications
| Product Name | MBM Triumph 5560 Programmable Cutter Package |
| Manufacturer | MBM |
| SKU | CU0493VP |
| Dimensions (H”xW”xD”) | 54 x 42 (64 w/ side tables) x 55 |
| Length Behind Blade (Inches) | 22.43 |
| Narrow Cut (Inches) | 1.25 |
| Cutting Width (inches) | 21.62 |
| Sheet Capacity | 1000 |
| Operation | Programmable Hydraulic |
| Type of cutter | Programmable Cutter |
| Cutting Height (Inches) | 3.75 |
| Blade Drive | Hydraulic |
| Paper Clamp | Adjustable Hydraulic |
| Back Gauge Setting | Electronic Hand Wheel |
| Warranty | 1 year |
| Country of Origin | Germany |
| Power Supply (Volts) | 115v, 60Hz, 20 amp dedicated line req. |
| User Type | Commercial |
| Optional Accessories | Side Tables |
| Applications | Print Shops, Copy Centers |
| Cutting Material | Paper |
| LED Laser Cut Line | No |
| Safety Feature | Comprehensive SCS Safety Package |
Product Description:
Features of MBM Triumph 5560 Automatic Paper Cutter
- Programmable hydraulic paper cutter with VRCut Software
- Clamping pressure adjustable between 1900 and 3800 psi
- Patented EASY CUT ensures safety with two hand operations
- Equipped with electronic hand wheel for manual back gauge positioning
- 7” Programmable module with multi lingual touch pad for the power back gauge
- Assembled with a tool holder on the rear side to keep tools within reach
- Dimensions of the product is 55" x 42" x 54"
- Comes with 1-year limited warranty excluding wearables
- Cutting width and height with false clamp is 21 5/8” and 3 3/4” respectively
- Programmable module with 99 program storage with 99 steps each
- Manufactured in Germany
The MBM Triumph 5560 paper cutter is an automatic programmable hydraulic with hydraulic adjustable clamp with adjustable pressure between 1900 and 3800 psi. The cutting width and height of is 21 5/8” and 3 ¾” which enables to cut through couple of hundred of papers at once making it ideal machine for a large office. The uniqueness of these cutters is that it is inclusive of the VRCut software. VRCut controller functions with cut-line indicator with full cut instructions displayed and notifies user at each step of the procedure and VRCut impose functions in which creates barcode for error free recall and printed guidance measure is provided to carry out accurate operations. The 5560-paper cutter is inclusive of variety of features like power back gauge, digital touchpad, IR safety light, two hand operation, disc brake, safety lock etc. for safe and precise paper cutting.
MBM Triumph 5560 Automatic Paper Cutter PackageThe automatic programmable 5560 cutter includes electric cutter to provide you with accurate results for your work place. The package includes six cutting sticks (AC0678), cutting knifes (AC0684) for accuracy and side tables 32” (CU0440) with increased work surface.
WarrantyTo ensures customer satisfaction the MBM triumph cutter comes with a 1-year limited warranty excluding wearables for your workplace to have the exclusive cutting experience.
